The New Standard for Direct Seed Drilling

MDH-1700 Dual Hopper

Designed for the direct drilling professionals. This is our top spec direct drill for planting grass, fodder crops, clover, cover crops and stewardship scheme mixes. And enables you to sow more than one type of seed at the same time.

  • A Dual Hopper Seed Drill allows you to apply fertiliser or a companion crop with your main crop – saving time and money!
  • Simple and reliable Dual Hopper Seed Drill – low operating costs, common parts, and a long working life
  • Two types of seed or seed & fertiliser can be applied together in one seed furrow – ideal for starter fertiliser or cover/companion cropping scenarios.
  • Dual Accord Metering Units, Dual Hopper (1700L total), One Hydraulic Fan
  • Same quality Moore wearing parts and frame components.
  • Grant Eligible in some areas
  • Learn Moore about System Moore

Have you got questions?

Get Call Back

Narrow row spacing

Narrow row spacing provides the crop with considerably higher competitiveness against weeds

This is important as more herbicide resistant weeds are on the increase.

Narrow rows also means the gaps between the rows close in faster which reduces the amount of moisture evaporation and soil erosion

The Original Moore Coulter System

Tungsten tipped coulters as standard, providing superior wear rates. It is more common for the discs to wear out before the coulters

Infinitely adjustable so that they can be adjusted for deeper/shallower disc cut or as the disc wears out

Accord Metering System

Tried and tested Accord metering system

Quick & easy to calibrate

Highly accurate sowing rates

Ability to sow down to the last quantity of seed, with most seed types

Perfect for all small seeds such as kale, stubble turnips, oilseed rape and grass

Rubber Arm Suspension System

Each seed coulter is fitted to a rubber suspended twin disc arm for optimum contour following

The heavy-duty design with high coulter pressure means the disc and coulter will not release easily.

However, if the disc and coulter encounter a larger stone or obstacle the whole arm assembly will quickly release and return to for working position.

Hydraulic Rear Packer

Precise drilling depth adjustment and coulter pressure

Seeding coulters can be totally suspended off the ground with all the weight on the packer roller, or all weight can be put on the discs to give maximum penetration into the soil

Useful feature for when field conditions change such as soft and hard areas of the field

Testimonials

Guttler Style Packer (Standard)

The Guttler Style Prisma roller provides the necessary seed to soil contact that every crop needs. This ensures strong tillage, longer lasting stands, and higher yields.

The unique Guttler Style self-cleaning roller has two cast iron Prisma rings working together on a 45/50cmØ roller. The smaller ring fits securely on the shaft whilst the larger ring runs on the inner shoulder of the smaller ring (like a breaker ring), giving a cleaning action to the outer surface and aids in breaking down any clods.

Optional Extras

Request More Info Get call back

Specifications

  • Row Spacing

    125mm

  • Number of Seeding Coulters

    24

  • Overall Width

    3100 mm

  • Overall Length

    3000 mm

  • Overall Height

    2300mm

  • Working Width

    2900mm

  • Unladen Weight (Approx)

    2500kg

  • Minimum Power Requirement (HP)

    120hp

  • Other standard features not listed above

    Hydraulic Drive Fan, LED Lights, Maintenance Free Bearings, Rear Step & Safety Rail, 415x5mm Disc Blades

  • Available Optional Extras

    Extra Weight Kit, Hydraulic Bout Marker Kit, Wired CCTV Camera Kit, Following Harrow Tine Kit, (Tramlining Option 1), (Tramlining Option 2), (Tramlining Option 3, (Optional RDS Artemis 3 ISOCAN ISOBUS Cable), Stocks 130L 2nd Hopper

  • Row Spacing

    90mm

  • Number of Seeding Coulters

    32

  • Overall Width

    3100 mm

  • Overall Length

    3000 mm

  • Overall Height

    2300mm

  • Working Width

    2900mm

  • Unladen Weight (Approx)

    2700kg

  • Minimum Power Requirement (HP)

    120hp

  • Other standard features not listed above

    Hydraulic Drive Fan, LED Lights, Maintenance Free Bearings, Rear Step & Safety Rail, 415x5mm Disc Blades

  • Available Optional Extras

    Extra Weight Kit, Hydraulic Bout Marker Kit, Wired CCTV Camera Kit, Following Harrow Tine Kit, (Tramlining Option 1), (Tramlining Option 2), (Tramlining Option 3, (Optional RDS Artemis 3 ISOCAN ISOBUS Cable), Stocks 130L 2nd Hopper
